microwave vacuum fruit dehydration machine/Rosebud Microwave Vacuum Dryer/vacuum belt microwave dryer

tea microwave dryer/Herb Leaves Microwave Drying Machine/ automatic microwave drying/ vacuum belt microwave dryer

Contact: Alex Wang
Cellphone: 0086 1531557378186-135 9881 2014
Skype: ujoin99

1. Specification of vacuum belt microwave dryer

vacuum belt microwave dryer

1)PCL Control
2)Safety and Environmenatl Microwave Tunnel Dryer
3)Drying Machine

2. structural composition of vacuum belt microwave dryer

1)Samsung original water-cooled magnetron.

2)Digital electronic microwave power.

3)Drying chamber equip with 3 flow wet system fan platoon.

4)PLC man-machine interface programming control.

5)The infrared temperature monitor (Germany).

6)Drying chamber with six material observation door (choke door, effectively prevent microwave overflow), with the door safety protection system with two groups of axial flow fan platoon is wet system.

7)Independent electrical control operation cabinet.

8)Equip with special cloth device.

3.Control system of vacuum belt microwave dryer

vacuum belt microwave dryer set up separate total control cabinet, PLC programmable control,

human-machine interface display.In the heater outlet equipped with infrared radiation temperature measuring

probe, measuring surface temperature of the material, through the thermometer display material temperature

in time, to monitor this case point temperature materials in a timely manner, and can set any temperature, according to the required temperature, lower limit setting can automatically adjust the heating tempe.

4. Schematic View of vacuum belt microwave dryer

5.Applicable Scope of vacuum belt microwave dryer

1)The flavorings spice

2)Subsidiary agricultural products, deep processing products of fruit,vegetable

3)Various dried meat, like beef, pork, chicken,duck, fish etc.

4)The grain, the deep manufactured products

5)Sterilization of beverage and the wine, the meat, the marine product, the roasted seeds and

nuts, and etc.
6)Chemical material,medicine tablet

7)Powder for various material

6. Features of vacuum belt microwave dryer

1)Machine material: food-grade stainless steel

2)Energy-saving more than 30%

3)High production efficiency

4)Improve product quality: nice color, good taste

5)Safety and pollution-free

6)Improve working conditions: PLC touch screen control, automatically operation

7.Advantage of vacuum belt microwave dryer

1.The vacuum belt microwave dryer set up separate total control cabinet, PLC programmable

control,human-machine interface display.In the heater outlet equipped with infrared radiation temperature

measuring probe, measuring surface temperature of the material, through the thermometer display material

temperature in time, to monitor this case point temperature materials in a timely manner, and can set any temperature, according to the required temperature, lower limit setting can automatically adjust the heating tempe.

2.Microwave from the top heater feed into the mouth, heated material can be directly to microwave energy, the loss is smaller than other factory, heating efficiency is about 15% higher, the material heating uniformity is more than 20% higher.

3.The core component of this vacuum belt microwave dryer ‘s main electronic components

used in microwave generato with high quality,long life,high reliability and can work continuously.

8.Detailes and assembly parts of vacuum belt microwave dryer

9.Images of vacuum belt microwave dryer

10.Service commitment of vacuum belt microwave dryer

Based on the abundant technical strength, complete detection means, excellent quality assurance system to ensure that the "quality first, customer supreme", responsible for equipment installation and debugging, technical service and technical training.

After installing the device,my company's technical staff will do equipment professional technical training and live demonstration for your company's Production operators.
