Sesame Quinoa gravity Table

Product Description

5XZ-5B Sesame Quinoa gravity Table

Introduction of 5XZ-5B Sesame Quinoa gravity Table:
The 5XZ-5B Sesame Quinoa gravity Table is the suction LLDe gravity table with closed air system protecting environment. 5XZ-5B Sesame Quinoa gravity Table is movable machinery mounted on elevator and wheels, suitable for plant, field worldand remote area.

Application of 5XZ-5B Sesame Quinoa gravity Table:
The 5XZ-5B Sesame Quinoa gravity Table can be used effectively to remove partially eaten, immature shriveled or broken seeds to ensure maximum quality of the final product.

worldPrinciple of 5XZ-5B Sesame Quinoa gravity Table:

By air altiration and sieve oscillation, the seed is fluidized and stratified. Heavy seed (good seed) sink into bottom layer of material on the sieve while the bad seed (LD seed) suLDends to the top layer. After stratified, materials goforward to the discharging part. Bottom layer good seed fall through the sieve discharge from outlets. The LD seed with bad quality will be discharged directly. Mixture quality seed through sieves and return back to feeding hopper via vibrating material reflow gear.

specification of 5XZ-5B Sesame Quinoa gravity Table:

Model and name	5XZ-3A	5XZ-3B	5XZ-5A	5XZ-5B
Dimension (L×W×H) mm	4000×1800×2750	4000×1800×2750	4000×1900×3100	4000×1900×3100
Dimension of sieve platform (L×W) mm	2000×325	2000×325	2000×625	2000×625
Capacity kg/h	3000	3000	5000	5000
Power kw	5	4.25	9.62	9
Weight kg	1200	1100	1600	1550
Cyclone dust separator	YES	NO	YES	NO

Photos of 5XZ-5B Sesame Quinoa gravity Table:

The following is another model gravity separotor, you also can consider it:

If your material has too many stones, you should consider use a destoner, please click the following picture:
